• For ammonia or Freon systems.
• For cold and freezing chambers.
• Own manufacture and design.
• Standard models and on demand.
• Coils for refrigeration cabins.
• Recycling of used evaporators.
• Evaporators for glycol systems.

COILS
Manufactured with seam steel tubing Ø 1/2".

FINS
Flat type, steel manufactured, 0.34 mm thick, pressed assemblied.

EVAPORATING BLOCK
The block is air tested, submerged in water, up to a pressure of 25 Kg/cm², before and after the hot dipped galvanized process is done. Minimun galvanized thickness: 50 microns.

MOTO FAN ASSEMBLIES
Each one compound by an axial flow helix, direct-connected to the electrical motor. Hoop and support plate made of steel, commercial quality, hot dipped galvanized.
Alternative in stainless steel AISI 304.

DEFROSTING SYSTEM
By means of water and/or hot gas.

SUPPORT STRUCTURE
Manufactured with regular steel structural shapes, hot dipped galvanized, with the necessary cross section in order to support the equipment, the air box and the water-drainage tray.

EXTERNAL CLOSING
Manufacturated with galvanized steel sheet Nº 20, with inner reinforcements. Alternative in stainless steel sheet AISI 304, or white PRFV 2.3 mm thick.

WATER-DRAINAGE TRAY
Manufatured in steel, hot dipped galvanized.
Alternative: stainless steel AISI 304.
Option for freezing chambers evaporators: Isolated tray with polystyrene or polyurethane, including a coil for hot gas defrosting system. Final coating in white PRFV 2.3 mm.
